Process Siemens XML exports.

1. Project upload

No XML loaded

Master SiteExport XML

Choose the XML once. All tool buttons below will use this file.

Active resource book

Cerberus FS20

Reports use the selected stored resource book until a newer one is uploaded.

Cerberus resource book

FS20 resource book

Checking stored resource books…

⇧

Polished report

Core engineering workbook: quantities, wiring order, interface schedule, DesigoCC datapoints and detector condition.

∑

System verification

Comprehensive HTML verification of XML integrity, system limits, C-NET/FDnet counts, network limits, references and customer-text quality.

⌁

3D network diagram

Siemens guide-style diagram using IP-addressed panels, gateways, switches/routers and XML routing data.

⌖

CAD import pack

Create Desigo CC Advanced CAD Import mapping files using logical address, Element ID and description attributes.

Help and visual guides

Step-by-step instructions for every function, including visual guide panels for CAD, Desigo CC and the Siemens configuration workflow.

✎

Customer text update

Configure replacement text and preview the expected output before generating the updated XML ZIP.

2. Customer text update preview

Live sample

Replacement format

Loop# / last 4 digits of IDnr + customer textExample: 1/1705 Disabled Alarm Room 364

Loop# / wiring order# + customer textExample: 1/17 Disabled Alarm Room 364

Remove existing prefix before first spaceOptional helper for old prefixed customer text.

Manual trim: remove first characters

Manual trim: remove last characters

Optional Siemens customer text exchange CSV Accepts sheets with columns like Area address; Section address; Zone address; Channel address; Customer text. The output ZIP will include a reproduced CSV with the Customer text column updated using the same XML workflow.

Normal devices use detection_customer_text only. Hardware customer text is used only for sounder beacon interbases and I/O modules.

Sample output

Select the master XML above to preview the first device text replacement.

Job progress

Idle

1. UploadWaiting for file

2. ValidatePending

3. ProcessPending

4. DownloadPending

Select the master XML, then choose a tool.

Download output
